KAMERA ZA VZVRATNO VOŽNJO CMOS Z NOSILCEM TSBCMINI 12/24V

KAMERA ZA VZVRATNO VOŽNJO CMOS
Z NOSILCEM BC MINI 12/24V

Rearview camera of small size, 12V / 24V, with on/off guide lines function, view angle of 170°, metal body.


Technical parameters:

• PC3089 - 1/3" chip
• option to enable / disable guide lines
• electronic aperture: 1/50 1/12000 sec.
• minimum illumination: 0.01 Lux
• signal-to-noise ratio:> 48dB
• TV system: NTSC (each display is compatible)
• effective points: 720x488
• number of TV lines: 600
• weather protection: IP68
• sensing angle: 170°
• video output: 1.0V / 75 Ohm
• white balance: automatically
• operating temperature from -30 °C to + 75 °C
• signal cable of 7m lenght, with CINCH / RCA connectors (male)
• power cord length 1m
• power supply 12V / 24V
• mirror image
• dimensions: 38 x 37 x 36mm (W x H x D) including the bracket


Note: The camera is designed for aftermarket radio units with RCA AV input. Connecting to an original radio unit may require to add the video adapter for parking camera!
